Product Description
| POLARIS FULLSIZE UTV's | Years |
| TM Ranger Full-Size 4x4 | 2004-06 |
| 425 Ranger Full-Size 2x4 | 2001-04 |
| 500 Ranger Full-Size 2x4 | 2001-08 |
| 500 Ranger Full-Size 4x4 | 2002-08 |
| 500 Ranger Full-Size 6x6 | 2002-05 |
| 700 Ranger Full-Size 4x4 | 2005-08 |
| 700 Ranger Full-Size 4x4 Crew | 2008-09 |
| 700 Ranger Full-Size 6x6 | 2006-09 |
PLEASE NOTE: If you have a four or more seater model you will need the wire extension kit due to the winch being farther from the battery. Select the option to add the wiring kit above.
Specifications:
- 100% MADE IN USA
- Constructed of 3/16" Grade 50 steel
- Unlike all other mount competitors, our mounts are metal bead blasted before they are powder coated for the best possible finish prep.
- Powder coated black for supreme durability
- Very easy to install
- Complete installation instructions included
- Mounts winch tucked back behind front bumper
- Satisfaction guaranteed
- Roller fairlead and winch not included
PLEASE NOTE: Check the listings below to see if this winch mount is compatible with your winch. You may need to add a roller fairlead in the options above.
Mount Designed to work with the following Winches:
- KFI: ST17 / S2000 / A2500 / A3000 / U4500 / U4500w / SE25 / SE35 / SE45 / SE45W
- WARN: A2000 / A2500 / U2500 / 1.5ci / 2.5ci / 2.5ce / 3.0ci / 3.0ce / 3.0s
- WARN: RT15 / RT25 / RT30 / XT15 / XT25 / XT30
- WARN: RT40 / XT40
- WARN: Vantage 2000-3000lbs / Provantage 2500-3500lbs
- WARN: Vantage 4000lbs / Provantage 4500lbs
- RAMSEY: ATV2500 / ATV3000
- SUPERWINCH: Terra25 / Terra35 / Terra 45 / LT2000 / LT2500 / LT3000 / LT4000ATV / LT4000UTV
- MILE MARKER: PE2.5 / PE 3.5 / VMX2.5 / PE2000 / PE3000 / PE2500 / PE3500
- CYCLE COUNTRY: Work Power 1500 and 2500 / Powermax 2500 and 3500
- BADLAND: 2000lb #68146 / 2500lb #61297 / 2500lb #61840 / 2500lb #61258
- BADLAND: 3000lb #68145 / 3500lb #61257 / 3500lb #61383 / 5000lb #68144 / 5000lb #61384
- CHAMPION: C10013 / C10014 / C10018 / 10020 / 10024 / 12053 / 12503 / 12551 / 13004 / 13050 / 13502 / 13501(requires rollers) / 14061 / 14001 / 14051 / 40252 / 14560
- CHAMPION: 14501 / 14551 / 14552 / 14008 / 40252 (4500lbs)
- CHAMPION: 10028 / 10032 / 12001 / 12002 / 13001 / 20049 / 20051 / 20249 / 30045 / 30145 / 12003
- CHAMPION: 14001 and 14061
- KEEPER CORP. TRAKKER: KT2500 / KT3000 / KT2500C / KT3000C / KT4000 / KT4000C
- KEEPER CORP. TRAKKER: KT2000
- Requires purchase of a roller Fairlead (add above) - SMITTYBILT: XRC 2.0
- SMITTYBILT: XRC 3.0 / XRC 4.0
- XGEAR: X3000 / X4000
- VENOM: 2000 / 2500 / 3000 / 3500 / 4000 / 4500 / 5000 (Hardcore Series)
- All with 3.00" x 4.875" Bolt Pattern mount-up
- All with 3.00" x 6.600" Bolt Pattern mount-up - Traveller: 1078302 / 1078088 / 1078311
- Possibly Many others with the below standard Mounting patterns
- 4-Hole (3.00" x 4.875" bolt pattern with Rollers that are 4.875" bolt pattern)
- 4-Hole WIDE (3.00" x 6.60" bolt pattern with Rollers that are 6.600" or 6.000" bolt pattern)
- 2-Hole (3.10" with Rollers that are 4.875" bolt pattern) - QUADBOSS: RP25 / RP35
Replacement Grilles:
Also available are replacement grilles. There are three different style grills depending on what winch you are installing. These replacement grills will allow for the clearance of your winches roller fairlead and clutch access. Add above if needed.
100562
Replacement grill works with the following winches
- KFI: S2000
- SUPERWINCH: LT2000
- MILE MARKER: PE2.5 / PE 3.5 / VMX2.5 / PE2000 / PE3000 / PE2500 / PE3500
- CYCLE COUNTRY: Work Power 1500
- BADLAND: 2000lb #68146 / 2500lb #61297 / 2500lb #61840 / 2500lb #61258
- CHAMPION: 10028 / 10032 / 12001 / 12002 / 13001 / 20049 / 20051 / 20249 / 30045 / 30145 / 12003
- KEEPER CORP. TRAKKER : KT2000 (Requires ATV-RF Rollers)
- SMITTYBILT: XRC 2.0
- Traveller: 1078302 / 1078088
- Possibly Many others with the below standard Mounting patterns
- 2-Hole (3.10" with Rollers that are 4.875" bolt pattern)
100563
Replacement grill works with the following winches
- KFI: ST17 / A2500 / A3000 / U4500 / SE25 / SE35 / SE45
- WARN: A2000 / A2500 / U2500 / 1.5ci / 2.5ci / 2.5ce / 3.0ci / 3.0ce / 3.0s
- WARN: RT15 / RT25 / RT30 / XT15 / XT25 / XT30
- WARN: Vantage 2000-3000lbs / Provantage 2500-3500lbs
- RAMSEY: ATV2500 / ATV3000
- SUPERWINCH: Terra25 / Terra35 / LT2500 / LT3000 / LT4000ATV
- MILE MARKER: PE2.5 / PE 3.5 / VMX2.5
- KOLPIN: 2500 / 3500 / 4500
- CYCLE COUNTRY: Work Power 2500 / Powermax 2500 and 3500
- BADLAND: 3000lb #68145 / 3500lb #61257 / 3500lb #61383
- CHAMPION: C10013 / C10014 / C10018 / 10020 / 10024 / 12053 / 12503 / 12551 / 13004 / 13050 / 13502 /13501(requires rollers) /
- CHAMPION: 14001 and 14061 / 14051 / 14560
- KEEPER CORP. TRAKKER: KT2500 / KT3000 / KT2500C / KT3000C
- SMITTYBILT: XRC 3.0 / XRC 4.0
- XGEAR: X3000 / X4000
- 4-Hole Standard (3.00" x 4.875" bolt pattern) - VENOM: 2000 / 2500 / 3000 / 3500 / 4000 / 4500 / 5000 (Hardcore Series)
- All with 3.00" x 4.875" Bolt Pattern mount-up - Possibly Many others with the below standard Mounting patterns
- 4-Hole (3.00" x 4.875" bolt pattern with Rollers that are 4.875" bolt pattern) - QUADBOSS: RP25 / RP35
100564
Replacement grill works with the following winches
- KFI: U4500w
- WARN: RT40 / XT40
- WARN: Vantage 4000lbs / Provantage 4500lbs
- SUPERWINCH: Terra 45 / LT4000UTV
- BADLAND: 5000lb #68144 / 5000lb #61384
- CHAMPION: 14501 / 14551 / 14552 / 14008 / 40252 (4500lbs)
- KEEPER CORP. TRAKKER: KT4000 / KT4000C
- VENOM: 3500 / 4000 / 4500 / 5000 (Hardcore Series)
- All with 3.00" x 6.600" Bolt Pattern mount-up - Traveller: 1078311
- Possibly Many others with the below standard Mounting patterns
- 4-Hole WIDE (3.00" x 6.60" bolt pattern with Rollers that are 6.600" or 6.000" bolt pattern)
